S200 circuit breaker, 6kA, 4P, curve C, 6A

Name: S200 circuit breaker, 6kA, 4P, curve C, 6A
SKU: 4009637
Price: 109.75 EUR
Availability: InStock

Product code: 4009637 | EAN: 4016779529174

S200 Circuit Breaker 4P C6 6kA

✓ Rated breaking capacity Icn in accordance with EN 60898 at 230 V: 6 kA

✓ Number of poles (total): 4

✓ Rated current: 6 A

✓ Tripping characteristic: C

✓ Active neutral: no

✓ Number of protected poles: 4

✓ Width in module units: 4

✓ Rated breaking capacity Icn in accordance with EN 60898 at 400 V: 6 kA

✓ Rated voltage: 400 V

✓ Installation depth: 69 mm

✓ Voltage type: AC/DC

✓ Rated insulation voltage Ui: 440 V

✓ Rated breaking capacity Icu (IEC 60947-2) at 230 V: 20 kA

✓ Rated impulse withstand voltage (Uimp): 4 kV

✓ Frequency: 50–60 Hz

✓ Additional device possible: yes

✓ Flush-fit installation (plasterwork): no

✓ Energy efficiency class: 3

✓ Overvoltage category: 3

✓ Connectable multi-strand conductor cross-section: 0...25 mm²

✓ Protection rating (IP): IP20

✓ Contamination level: 3

✓ Connectable conductor cross-section (single-core): 0...35 mm²

✓ Operating ambient temperature: -25…55 °C

✓ Explosion-proof: no

✓ Power dissipation: 8 W

✓ Product Carbon Footprint (CO₂): Supplier’s declaration

ABB Cebeo

109.75 €
